Application: Indoor
Product Category: Downlight
Type: Y
Mounting Type: Recessed
Trim: Square
Housing Color: White, Black
Reflector Color: Matt, Black, White, Gold
IP: 20 - (LED Module IP 54)
CCT: Dim-to-Warm, 2700K, 3000K, 4000K
CRI: 80, 90, 95
LED Output: ≤3200lm
System Output: ≤2400lm
Lifetime: 50000h@L80B10
Standard Deviation: SDCM: 3
LED Chip: CITIZEN, BRIDGELUX
Beam Angle: 15°, 20°, 25°, 35°, 60°
UGR: <19
LED Driver: None, ON-OFF, Phase Dim, 0-10V Dim, DALI Dim
LED Power: 15W, 18W, 22W, 24W, 26W
System Power: 18W, 22W, 26W, 28W, 30W
LED Voltage: 2*31V, 2*33V, 2*36V
LED Current: 250mA, 350mA
Measurements: 155mm x 85mm
Cutout: 145mm x 75mm
Ceiling Height: 129mm, 150mm
Pivot: Max. 30°
Rotation: 355°
Housing Color: White
Housing Color: White
Housing Color: Black
Housing Color: Black
